Specifications 131
Ports and Connectors
External Connectors
Audio microphone, line-in, line-out, side-surround,
center/LFE, rear-surround
IEEE 1394 6-pin serial connector
Network adapter RJ-45 port
PS/2 keyboard/mouse 6-pin mini-DIN connector
USB 4-pin USB 2.0-compliant connector
S/PDIF Toslink optical connector
Systemboard Connectors
IDE drive one 40-pin connector
Serial ATA four 7-pin connectors
Floppy drive one 34-pin connector
Fan three 4-pin connectors
PCI two 124-pin connectors
PCI Express x1 one 36-pin connector
PCI Express x8 one 98-pin connector
PCI Express x16 two 164-pin connector
