Using Multimedia 59
4
Plug all three connectors from the other end of the component video cable
into the component video-input connectors on the TV. Make sure that the
red, green, and blue colors of the cable match the colors of the TV input
connectors.
5
Plug the single-connector end of the audio cable into the headphone
connector on the computer.
6
Plug the two RCA connectors on the other end of the audio cable into the
audio input connectors on your TV or audio device.
7
Turn on the TV, turn on any audio device that you connected (if applicable),
and then turn on the computer.
8
See "Enabling the Display Settings for a TV" on page 63 to ensure that the
computer recognizes and works properly with the TV.
Component Video and S/PDIF Digital Audio
1 S-video TV-out connector 2 component video adapter
1 2
