DeLonghi DE 60 E - Page 38

38
REMOVING THE INNER
PANE OF GLASS
To clean the inner pane of the oven
door on both sides operate as follows:
– Open the door to the full extent (fig.
40).
– Open the lever A completely on the
left and right hinges (fig. 41).
– Gently close the door (fig. 42) until left
and right hinge levers A are hooked to
part B of the door (fig. 41).
– Remove the seal G by unhooking the
no. 3 fixing hooks (fig. 43).
– Gently pull out the inner pane of
glass (Fig. 44).
– Clean the glass with an appropriate
cleaner. Dry thoroughly, and place
on a soft surface.
– Now you can also clean the inside of
the outer glass.
B
A
Figure 42
Figure 41
Figure 40
Figure 43
A
B
G
Figure 44
