20
Burners
T
hey can be removed and washed with soapy water only.
They will remain always perfect if cleaned with products used for silverware.
After cleaning or wash, check that burner-caps and burner-heads are dry before placing
them in the respective housings.
It is very important to check that the burner flame distributor and the cap has been correctly
positioned - failure to do so can cause serious problems.
Note: To avoid damage to the electric ignition do not use it when the burners are
not in place.
Correct replacement of the burners
It is very important to check that the burner flame distributor F and the cap C has been cor-
rectly positioned (see fig. 6.1 - 6.2) - failure to do so can cause serious problems.
Check that the electrode “S” (fig. 6.1) is always clean to ensure trouble-free sparking.
Note:
The electrode S must be very carefully cleaned.
S
F
C
Fig. 6.1
Fig. 6.2
