560
50
585
FITTING THE OVEN INTO A
COLUMN
The cabinet should have the
dimensions as per fig. 8.
Furthermore it is necessary that the
oven is provided with a chimney as per
fig. 9.
If the column unit reaches the ceiling
an outlet must be provided through
which air can flow to the outside
; ;
50 mm
50 550
Figure 8
Figure 9
10
