Once the area to install the water filter is determined, follow the steps below:
1. Screw the filter holders on the wall. Make sure the distance between the
filter holders is suitable to hold the water filter in place. The water filter
should be positioned vertically.
2. Measure the distance between the water filter and the water tap, and also
the distance between the water filter and the fridge. Cut the water hose
into 2 water hoses accordingly to the measured distances.
Remove the 2 clips from the water filter then pull out the 2 stoppers.
Fully insert the water hoses into the water-in and water-out ends of the
filter. Then re-attach the 2 clips, making sure each clip locks the water
hose firmly
3. To connect to the water tap, screw the adaptor to the
water tap outlet. Then connect the water hose that is
connected to the water-in end of the water filter.
4. Open the water tap to flush the new water filter. In
case the water colour is darkish, it is normal for first
use. Continue flushing until the water colour becomes
normal.
5. After the water colour becomes normal, connect to
the unit. Attach the one end of the adaptor to the
unit’s water hose, then connect the water hose that is
connected to the water-out end of the water filter into the other end of the adaptor.
6. After installation is completed, dispense several glasses of water before use.
water in
water out
It is important to connect the water hoses correctly to the water-in and water-out end
of the water filter.
• Do not bend the water hoses.
• Do not put heavy things on top of the water hoses.
• After installation is completed, turn on the water tap. Check and make sure there is no
leakage in every connection points.
water
in
water
out
Stopper
Stopper
Clip
Water Filter
15
