41
Fig. 10.4
J
J
Fig. 10.5
INJECTORS REPLACEMENT OF THE TOP BURNERS
If the injectors are not supplied they can be obtained from the “Service
Centre”.
The diameter is marked on the injector in cents of millimetre.
Select the injectors to be replaced according to the “Table for the choice of the injec-
tors” (page 43).
To replace the injectors:
– Remove the gratings, the burner and the covers;
– Using a wrench, substitute the nozzle injectors “J” (Figs. 10.4 - 10.5) with those most
suitable for the kind of gas for which it is to be used.
The burners are conceived in such a way so as not to require the regulation of the pri-
mary air.
Conversion to Natural Gas or to LPG
