3-3
Navigation Audio System
Setting Preset Stations
Up to 30 stations, six AM, six FM1, six FM2, six XM1, and six XM2, if equipped, can be programmed using the
six screen buttons on the bottom of each band menu. To set preset stations, do the following:
1. Turn the audio system on.
2. Press the BAND hard key to select AM, FM1, FM2, XM1, or XM2, if equipped.
3. Locate the desired station using the SEEK hard key or the tuning knob.
4. Press and hold one of the six preset screen buttons until you hear a beep. Whenever you press that
screen button while in that band menu, the station you set will return.
5. Repeat the steps for each preset and source.
Band Menu
If the radio is on while the navigation system is not in use, this
band menu will display the current audio information, as well
as list the presets for the current band.
If the radio is on while the navigation system is in use, a
smaller band menu will appear, located on the left side of the
map screen.
