BILGEPUMPSYSTEM
InbilgepumpsystemforD-29.2therearetwobilgepumps:
-auto-manualbilgepump(electric);
-manualbilgepump(manual).
AUTO-MANUALBILGEPUMP
Pumpmodel:JABSCO37202-210A(120W).
Auto-manualbilgepump,asthenameindicates,hastwofunctions:
automaticandmanual.Whenyouwanttousetheautomaticpump
youshouldturnonontheswitchboardpanel
fuse,andthenonthe
pumppanel(photo1)turntheswitchto
position.Inordertousethemanualoption
youshouldturntheswitchonthepumppanel
to position
bilgeauto-manual
auto
manual .
1. Bilgepumppanel
35/99
MANUALBILGEPUMP
Manualbilgepumpwiththeoutputof50l/min.
Islocatedoncockpitstarboard.Bilgesuctionpipe
islocatedunderthefloorinthemessroom.Remember
toalwayshaveaneasyaccesstothepumplever.
33.
Thedistributionofparticularelementsofbilgepumpsystemontheboat-refer
tobilgesystemschemeonpage
