BILGEPUMP PANEL
Bilgepump:
-
-
-
-
( ),
o
-
( )
inordertocheckthebilgepumpyoushouldturn
themasterhouseswitc offandturnonthebilge
autoswitchontheswitchboard
h
automaticmode turnon ontheadditional
panel photoontheright andthenaddsomewater
tothepumpsens rtocheckifthepumpstarts
automatiacally.
manualmode turnmanualmodeontheadditional
panel photoontheright andcheckifthepumpworks.
automode
SWITCHBOARDPANELLIGHTING
Blackbuttoninasilverframeisusedtoturnonthe
lightingofthemarkingsontheswitchboardpanel,
bilgepumppaneland indicatorDC/TLM .
CHARGINGWITHQUICK
BATTERYCHARGER50A-115/230V
Youshouldturnonthechargeronthe
switchboardpanelwith12Vmasterswitchesturnedoff
becausetheinstallationwasdesignedtomakeitpossible
tochargeallthebatteriesautomaticallywithoutboatuser
interference.Duringthefirstphaseyoushouldturnthe
chargeron(biggreenbutton)andcheckthediodes
(markedwitharrowsonthepicture)toseeifitworks:
thegreenandyellowdiodesmeanthatthecharger
startedandworksproperly.Thenyouturnonthemaster
houseswitchandDC/TLMindicator,whichyouswitchto
DCAMPSfunction.Iftheindicatorshowsthecurrentvoltage
e.g.7Athismeansthatthechargerproperlychargesthehouse
batteries.Atthesametimeyoumayturnonseveralreceiversandobserve
whathappensontheindicator.Ifalltheactivitieswerecarriedoutinaccordance
withtheaboveinstructions,thechargerwillworkproperlyandensuresyouthatthe
electricinstallationisproperlyinstalled.
115/230V
