Delphia 33 - Page 70

SENSORSCONNECTION
67/99
INTERFASEMODULE
WASTE TANK TLM
SENDER
WATER
WASTE
FUEL
DC/TLMMETER
12VDC
yellowTLM
purpleF+PW
redF
switch
Wastewatertanksensor
Freshwatertanksensor
Fueltanksensor
Bilgepumppanelbacklight
Switchboardpanelbacklight
