LIGHTINGINSTALLATIONSCHEME(LEDlampsversion)
73/99
Lampsinthemessroomcanbeturnedonandturnedoff
withaswitchplacenexttothestairs.Itworksonlyifthehouse
masterswitchandswitchboard(cabinlight)switchisturnedon
wiresinthehull
wiresinthedeck
wiresinthedeck
Distributionbusintheswitchboard
Masterisolator(switch)
Lampwithoutswitch(1W)
Lampwithintegralswich(1W)
Switch(ontheswitchboardpanel)
Switchoflampsinthemessroom
(0-off,1-left,2-right,3-both)
Fuseintheswitchboard
