Dipswitch 2 (Free run to stop)
This sets the stop mode. Its identical to setting Pr02 -02=1. It means the stop mode is
free run or coast.
Dipswitch 2 = OFF
When keypad connected Pr02-02 can be set as needed.
Dipswitch 2 = ON
Pr02-02 is set to 1 automatically and when keypad connected other setting results
in "Err" on display.
Dipswitch 3 (ACI)
This sets the frequency command source to ACI.
Dipswitch 3 = OFF
Pr02-00 sets the Frequency command source, see manual.
Dipswitch 3 = ON
The Frequency command source is ACI 4~20mA, independently of the ACI/AVI
dipswitch.
Normally when you set Pr02-00=2 to select ACI/AVI2 and Pr04-19=0 (ACI) or 1 (AVI2),
you can select with the dipswitch ACI/AVI the input to be ACI with 4-20mA or AVI2 with
0-10V.
If input ACI 4-20mA is selected, either via dipswitch 3 or via Pr02.00=2, Pr04-19=0
(default) with dipswitch ACI/AVI=ACI it gives "Aerr" on display and the FAULT LED
lights up because the current is >0mA and <4mA. In case of keypad, the fault "AErr"
can be reset by RESET command (via digital input of keypad depending on Pr02.01)
provided cause of the fault is removed. The FAULT LED can only be reset by power
off/power on, also if the cause of the fault is removed.
In case you want to use AVI2, you need to set Pr04-19=1, then Pr02-00=2, then set
switch ACI/AVI=AVI to avoid "AErr" error.
Therefore, it is recommended to set all dipswitches 1, 2, 3 to OFF in case you use
the keypad.
