C2000/CP2000/CFP2000
Q WPL cannot make connection to C2000. Why?
A Please check the setting of Pr09-35. The default station address for PLC is 2. You
need to select station address 2 when setting up the connection to WPL
*VFDSoft uses station address 1 (as set in Pr09-00).
Q Which elements are supported by KPC-CC01?
A In the latest firmware KPC1021-20110720 and higher, the following elements are
available.
1 Static text Totally supported
2 Numeric display
When the referred value is from VFD then the integer/decimal
number is decided by the control board.
When the referred value is from PLC then value type can be
Unsigned, Signed and Hex, and the decimal number is available
(to be decided by user).
Frame/Font/Alignment settings are available but always with
leading zero
3 Bit lamp Not available
4 Word lamp Not available
5 Static bitmap Totally supported
6 Scale Totally supported
7
Bar graph
The value type only support Unsigned and Signed , the value
length only support 16 bits
