1- AUTO mode
1- AUTO mode ................................................................................ 3
2- Technical unit indicator lights ...................................................... 3
3- Home automation functions ........................................................ 4
4- Date and time settings ................................................................ 4
5- Control output temperature settings (pellet stove) ...................... 5
6- Consumption data display .......................................................... 7
7- Programming ..............................................................................8
8- Days home ............................................................................... 10
9- Absence ................................................................................... 10
10- Heating override ..................................................................... 11
11- DHW override ......................................................................... 11
12- AUTO mode ............................................................................ 12
13- Help ........................................................................................ 13
Contents
CALYBOX monitors the active programme in the 2 zones and
controls the control output (pellet stove).
• Heating and DHW (Domestic Hot Water) overrides possible.
• Access to consumption data (
),
• Changeover to standby after a 30 seconds time-out period
Override
(
/ )
by zone
Consumption
data display
Hot water tank
override
Temperature
measured
Time
Control output
start
Day of the
week
2- Technical unit indicator lights
CALYBOX
1
Ti1Ti2 Ti3
3 5 7
9
T
C
BUS A
246810
11
4VA
230V~50Hz
N
FP2
15
FP3
16 17 19 2018
13
FP1
12
14
L
100mA max.
Ref. : 4100793
BUS
T
C
3A - 230V
~
Bus indicator light
Blinks in sync with the data
Steady blinking = Bus fault
Off = Power supply failure
Electronic meter indicator light
On = Normal operation
Blinking = remote-info fault
Load control indicator light
On = Load control in progress
Blinking = Pilot wire wiring fault
DHW (Domestic Hot Water) indicator
light
On = ON
Off = OFF
"Control output" indicator light
On = ON
Off = OFF
