Delta Electronics ASDA-A2 Series User Manual

Chapter 1 Unpacking Check and Model Explanation
1.3 Servo Drive and Servo Motor Combinations
The table below shows the possible combination of Delta ASDA-A2 series servo drives and
ECMA series servo motors. (Please refer to Section 1.2 for model explanation)
1.3.1 220V Series
Power Servo Drive Servo Motor
100W
ASD-A2-0121- ECMA-C10401S (S=8mm)
200W
ASD-A2-0221- ECMA-C10602S (S=14mm)
400W
ASD-A2-0421-
ECMA-C10604S (S=14mm)
ECMA-C108047 (7=14mm)
ECMA-E11305S (S=22mm)
ECMA-G11303S (S=22mm)
750W
ASD-A2-0721-
ECMA-C10807S (S=19mm)
ECMA-G11306S (S=22mm)
1000W
ASD-A2-1021-
ECMA-C11010S (S=22mm)
ECMA-E11310S (S=22mm)
ECMA-G11309S (S=22mm)
1500W
ASD-A2-1521- ECMA-E11315S (S=22mm)
2000W
ASD-A2-2023-
ECMA-C11020S (S=22mm)
ECMA-E11320S (S=22mm)
ECMA-E11820S (S=35mm)
3000W
ASD-A2-3023-
ECMA-E11830S (S=35mm)
ECMA-F11830S (S=35mm)
4500W
ASD-A2-4523-
ECMA-F11845S (S=35mm)
5500W
ASD-A2-5523-
ECMA-F118553 (3=42mm)
7500W
ASD-A2-7523-
ECMA-F118753 (3=42mm)
NOTE
1) The boxes () at the ends of the servo drive model names are for optional configurations (Full-
close control, CANopen, DMCNET and extension port for digital input). For the actual model
name, please refer to the ordering information of the actual purchased product.
2) The boxes () in the servo motor model names are for optional configurations (keyway, brake
and oil seal).
The drives shown in the above table are designed according to the three multiple of rated
current of motors shown in the above table. If the drives which are designed according to the
six multiple of rated current of motors are needed, please contact our distributors or your
local Delta sales representative.
1-6 Revision January 2011
