Chapter 1 Unpacking Check and Model Explanation
Revision January 2011 1-7
1.3.2 400V Series
Power Servo Drive Servo Motor
750W
ASD-A2-0743-
ECMA-J10807S (S=19mm)
1000W
ASD-A2-1043-
ECMA-K11310S (S=22mm)
1500W
ASD-A2-1543-
ECMA-K11315S (S=22mm)
2000W
ASD-A2-2043-
ECMA-K11320S (S=22mm)
3000W
ASD-A2-3043-
ECMA-L11830S (S=35mm)
4500W
ASD-A2-4543-
ECMA-L11845S (S=35mm)
5500W
ASD-A2-5543-
ECMA-L118553 (3=42mm)
*7500W
ASD-A2-7543-
ECMA-L118753 (3=42mm)
*7.5kW models will be available soon.
NOTE
1) The boxes () at the ends of the servo drive model names are for optional configurations (Full-
close control, CANopen, DMCNET and extension port for digital input). For the actual model
name, please refer to the ordering information of the actual purchased product.
2) The boxes () in the servo motor model names are for optional configurations (keyway, brake
and oil seal).
The drives shown in the above table are designed according to the three multiple of rated
current of motors shown in the above table. If the drives which are designed according to the
six multiple of rated current of motors are needed, please contact our distributors or your
local Delta sales representative.
The servo drives shown in the above two tables are designed for use in combination with the
specific servo motors. Check the specifications of the drives and motors you want to use.
Also, please ensure that both the servo drive and motor are correctly matched for size (power
rating). If the power of motor and drive is not within the specifications, the drive and motor
may overheat and servo alarm would be activated. For the detail specifications of servo drives
and motors, please refer to Chapter 12 “Specifications”.
