Chapter 8 Servo Parameters
8-70 Revision January 2011
Display Format: Decimal
Settings:
This parameter is used to set the capacity of the applicable regenerative resistor.
Model Default
For 1.5kW and below
models
60W
For 2kW to 4.5kW models 100W
5.5kW 0W
P1 - 54
PER Positioning Completed Width Address: 016CH, 016DH
Default: 12800 Related Section: Table 8.A
Applicable Control Mode: PT , PR
Unit: pulse
Range: 0 ~ 1280000
Data Size: 32-bit
Display Format: Decimal
Settings:
In PT mode, when the error pulse numbers is less than the setting value of parameter
P1-54, TPOS (At positioning completed signal) will be activated.
In PR mode, when the difference in pulse number between the target position and the
actual position is less than the setting value of parameter P1-54, TPOS (At positioning
completed signal) will be activated.
P1 - 55
MSPD Maximum Speed Limit Address: 016EH, 016FH
Default: rated speed Related Section: N/A
Applicable Control Mode: ALL
Unit: r/min
Range: 0 ~ Max. speed
Data Size: 16-bit
Display Format: Decimal
Settings:
This parameter is used to set maximum motor speed. The default setting is rated speed.
