Chapter 8 Servo Parameters
Revision January 2011 8-95
P2 - 44
DPH2
Notch Filter Attenuation Rate 2
(Resonance Suppression)
Address: 0258H, 0259H
Default: 0 Related Section:
Applicable Control Mode: ALL Section 6.3.7
Unit: dB
Range: 0 ~ 32
Data Size: 16-bit
Display Format: Decimal
Settings:
This parameter is used to set magnitude of the resonance suppression that is set by
parameter P2-43. If P2-44 is set to 0, the parameters P2-43 and P2-44 are both disabled.
P2 - 45
NCF3 Notch Filter 3 (Resonance Suppression) Address: 025AH, 025BH
Default: 1000 Related Section:
Applicable Control Mode: ALL Section 6.3.7
Unit: Hz
Range: 50 ~ 2000
Data Size: 16-bit
Display Format: Decimal
Settings:
This parameter is used to set third resonance frequency of mechanical system. It can be
used to suppress the resonance of mechanical system and reduce the vibration of
mechanical system.
If P2-45 is set to 0, this parameter is disabled.
P2 - 46
DPH3
Notch Filter Attenuation Rate 3
(Resonance Suppression)
Address: 025CH, 025DH
Default: 0 Related Section:
Applicable Control Mode: ALL Section 6.3.7
Unit: dB
Range: 0 ~ 32
Data Size: 16-bit
Display Format: Decimal
Settings:
This parameter is used to set magnitude of the resonance suppression that is set by
parameter P2-45. If P2-46 is set to 0, the parameters P2-45 and P2-46 are both disabled.
