Chapter 8 Servo Parameters
8-108 Revision January 2011
4: Modbus ASCII mode, <8,E,1>
5: Modbus ASCII mode, <8,O,1>
6: Modbus RTU mode, <8,N,2>
7: Modbus RTU mode, <8,E,1>
8: Modbus RTU mode, <8,O,1>
P3 - 03 FLT Transmission Fault Treatment Address: 0306H, 0307H
Default: 0 Related Section: Section 9.2
Applicable Control Mode: ALL
Unit: N/A
Range: 0 ~ 1
Data Size: 16-bit
Display Format: Hexadecimal
Settings:
This parameter is used to determine the operating sequence once a communication
fault has been detected. If '1' is selected, the drive will stop operating upon detection
the communication fault. The mode of stopping is set by parameter P1-32.
0: Display fault and continue operating
1: Display fault and decelerate to stop operating (deceleration time is determined by
parameter P5-03)
P3 - 04 CWD Communication Time Out Detection Address: 0308H, 0309H
Default: 0 Related Section: Section 9.2
Applicable Control Mode: ALL
Unit: sec
Range: 0 ~ 20
Data Size: 16-bit
Display Format: Decimal
Settings:
This parameter is used to set the maximum permissible time before detecting a fault
due to communication time out. When P3-04 is set to a value over than 0, it indicates
this parameter is enabled. However, if not communicating with the servo in this period
of time, the servo drive will assume the communication has failed and show the
communication error fault message.
When P3-04 is set to 0, this parameter is disabled.
