Chapter 8 Servo Parameters
Revision January 2011 8-151
P5 - 76★
CPRS Capture 1st Position Reset Data Address: 0598H, 0599H
Default: 0 Related Section:
Applicable Control Mode: ALL Section 7.10
Unit: N/A
Range: -1073741824 ~ +1073741823
Data Size: 32-bit
Display Format: Decimal
Settings:
Refer to P5-39 for explanation.
P5 - 77
CSAX Position of CAPTURE SYNC AXIS Address: 059AH, 059BH
Default: 0 Related Section: N/A
Applicable Control Mode: ALL
Unit: N/A
Range: -2147483648 ~ +2147483647
Data Size: 32-bit
Display Format: Decimal
Settings:
This position will be synchronized with the capture signal. When capture operation is
actived every two times, the offset value of this SYNC axis will be equal to the value of
P5-78 (no accumulation errors, for single direction operation only).
This parameter can be used as the position source of E-Cam master axis.
Please note:
ASDA-A2 series L type models does not provide Electronic Cam (E-Cam) function.
P5 - 78 CSDS
Interval Pulse Number of CAPTURE SYNC
AXIS
Address: 059CH, 059DH
Default: 100 Related Section: N/A
Applicable Control Mode: ALL
Unit: pulse
Range: 10 ~ +100000000
Data Size: 32-bit
Display Format: Decimal
Settings:
This parameter is used to set the offset value of this SYNC axis when capture operation
is activated every two times.
Please note:
This parameter can be set only when capture operation is stopped (Refer to P5-39).
