Chapter 8 Servo Parameters
8-154 Revision January 2011
Display Format: Decimal
Settings:
After receiving the pulse number P of master axis, the shaft of E-Cam will rotate M
cycles. It indicates that there are M cycles of the E-Cam table.
Please note:
1. This parameter can be set only when E-Cam function is stopped (Refer to P5-88).
2. ASDA-A2 series L type models does not provide Electronic Cam (E-Cam) function.
P5 - 84 ECMP E-Cam: Pulse Number of Master Axis (P) Address: 05A8H, 05A9H
Default: 3600 Related Section:
Applicable Control Mode: PR Section 7.11
Unit: N/A
Range: 10 ~ 1073741823, (P5-82 x P5-83) ＜＝ P5-84 and (P5-82 x P5-84) ＜＝
2147483647
Data Size: 32-bit
Display Format: Decimal
Settings:
After receiving the pulse number P of master axis, the shaft of E-Cam will rotate M
cycles. It indicates that there are M cycles of the E-Cam table.
Please note:
1. This parameter can be set only when E-Cam function is stopped (Refer to P5-88).
2. The firmware version V1.018 and later models: This parameter can be set any time.
3. ASDA-A2 series L type models does not provide Electronic Cam (E-Cam) function.
P5 - 85 ECME E-Cam: Engage Area Number Address: 05AAH, 05ABH
Default: 0 Related Section:
Applicable Control Mode: PR Section 7.11
Unit: N/A
Range: 0 ~ (P5-82 -1)
Data Size: 16-bit
Display Format: Decimal
Settings:
This parameter is used to set the E-Cam area number when the electronic gear is
engaged.
Please note:
ASDA-A2 series L type models does not provide Electronic Cam (E-Cam) function.
