Chapter 8 Servo Parameters
Revision January 2011 8-163
Z: EV3 settings
0: When EV3 is ON, no position command is triggered.
1 ~ D: When EV3 is ON, position command P51 ~ P63 is triggered.
U: EV4 settings
0: When EV4 is ON, no position command is triggered.
1 ~ D: When EV4 is ON, position command P51 ~ P63 is triggered.
P5 - 99 EVOF
Event Falling-edge Trigger Command
(ON OFF)
Address: 05C6H, 05C7H
Default: 0 Related Section: N/A
Applicable Control Mode: PR
Unit: N/A
Range: 0000 ~ DDDDh
Data Size: 16-bit
Display Format: Hexadecimal
Settings:
This parameter is used to trigger the position command when DI signal, EV1 ~ EV4
(Event trigger command 1 ~ 4) are OFF (inactivated).
Display U Z Y X
Range 0 ~ D 0 ~ D 0 ~ D 0 ~ D
X: EV1 settings
0: When EV1 is OFF, no position command is triggered.
1 ~ D: When EV1 is OFF, position command P51 ~ P63 is triggered.
For example, when the setting value of X is set to 1 while EV1 is OFF, the position
command P51 is triggered. When the setting value of X is set to 2, the position
command P52 is triggered, and so on.
Y: EV2 settings
0: When EV2 is OFF, no position command is triggered.
1 ~ D: When EV2 is OFF, position command P51 ~ P63 is triggered.
Please note:
The DI signals, EV3 and EV4 are avaiable for the firmware version V1.009 and later
models.
Z: EV3 settings
0: When EV3 is OFF, no position command is triggered.
1 ~ D: When EV3 is OFF, position command P51 ~ P63 is triggered.
U: EV4 settings
0: When EV4 is OFF, no position command is triggered.
1 ~ D: When EV4 is OFF, position command P51 ~ P63 is triggered.
