Chapter 8 Servo Parameters
8-162 Revision January 2011
Failure code: F062h The setting value of P5-94 has exceeded the
specification (1 ~ 65535)
Failure code: F063h The setting value of P5-95 has exceeded the
specification (1 ~ 65535)
Failure code: F064h The setting value of P5-96 has exceeded the
specification (300000 ~ 2500000)
Failure code: F065h The address specified by P5-81 is too big. The space
of the data array is not sufficient.
Failure code: F066h The setting value of P5-82 should be set to 7;
otherwise this macro command can not be executed.
Failure code: F067h Data calculation error. Please decrease the setting
value of P1-44 and P1-45.
Please note:
ASDA-A2 series L type models does not provide Electronic Cam (E-Cam) function.
P5 - 98 EVON
Event Rising-edge Trigger Command
(OFF ON)
Address: 05C4H, 05C5H
Default: 0 Related Section: N/A
Applicable Control Mode: PR
Unit: N/A
Range: 0000 ~ DDDDh
Data Size: 16-bit
Display Format: Hexadecimal
Settings:
This parameter is used to trigger the position command when DI signals, EV1 ~ EV4
(Event trigger command 1 ~ 4) are ON (activated).
Display U Z Y X
Range 0 ~ D 0 ~ D 0 ~ D 0 ~ D
X: EV1 settings
0: When EV1 is ON, no position command is triggered.
1 ~ D: When EV1 is ON, position command P51 ~ P63 is triggered.
For example, when the setting value of X is set to 1 while EV1 is ON, the position
command P51 is triggered. When the setting value of X is set to 2, the position
command P52 is triggered, and so on.
Y: EV2 settings
0: When EV2 is ON, no position command is triggered.
1 ~ D: When EV2 is ON, position command P51 ~ P63 is triggered.
Please note:
The DI signals, EV3 and EV4 are avaiable for the firmware version V1.009 and later
models.
