Chapter 11 Specifications
11-26 Revision January 2011
11.5.2 400V Series
Order P/N: ASD-A2-0743; ASD-A2-1043; ASD-A2-1543 (750W ~ 1.5kW)
Power A B C D E Weight
750W ~ 1.5kW 216 (8.50) 203 (7.99)
82 (3.23)
62 (2.44)
203 (7.99) 2.89 (6.36)
NOTE
1) Dimensions are in millimeters (inches); Weights are in kilograms (kg) and (pounds (lbs)).
2) Actual measured values are in metric units. Dimensions and weights in (imperial units) are
for reference only.
3) Dimensions and weights of the servo drive may be revised without prior notice.
