Delta Electronics ASDA-A2 Series

Chapter 3 Connections and Wiring
Revision January 2011 3-17
3.2.5 Encoder Connector Specifications
The boxes () in the model names are for optional configurations. (Please refer to section
1.2 for model explanation.)
Motor Model Name Encoder Connector
Terminal
Identification
ECMA-J10807S (750W)
HOUSING：AMP (1-172161-9)
A
ECMA-K11310S (1000W)
ECMA-K11315S (1500W)
ECMA-K11320S (2000W)
ECMA-L11830S (3000W)
ECMA-L11845S (4500W)
ECMA-L118553 (5500W)
ECMA-L118753 (7500W)
B
Terminal
Identification
T+ T-
Reserved Reserved Reserved Reserved
DC+5V GND
BRAID
SHELD
A
1
(Blue)
4
(Blue/
Black)
- - - -
7
(Red &
Red/White)
8
(Black &
Black/White)
9
B A B - - - - S R L
