Chapter 3 Connections and Wiring
3-26 Revision January 2011
3.4.2 Signals Explanation of Connector CN1
The Tables 3.A, 3.B, & 3.C detail the three groups of signals of the CN1 interface. Table
3.A details the general signals. Table 3.B details the Digital Output (DO) signals and Table
3.C details the Digital Input (DI) signals. The General Signals are set by the factory and
can not be changed, reprogrammed or adjusted. Both the Digital Input and Digital Output
signals can be programmed by the users.
Table 3.A General Signals
Signal Pin No Details
Wiring Diagram
(Refer to 3.3.4)
V_REF 42
1. Motor speed command: -10V to +10V,
corresponds to -3000 ~ +3000 r/min speed
command (Factory default setting).
2. Motor speed command: -10V to +10V,
corresponds to -3 ~ +3 rotations position
command (Factory default setting).
C1
Analog
Signal
Input
T_REF 18
Motor torque command: -10V to +10V,
corresponds to -100% to +100% rated torque
command.
C1
Analog
Monitor
Output
MON1
MON2
16
15
Monitor operation status: Motor characteristics
such as speed and current can be represented
by analog voltages. The drive provides two
channels which can be configured with the
parameter P0-03 to output the desired
characteristics.
Please reference the parameter P0-03 for
monitoring commands and P1-04 / P1-05 for
scaling factors.
Output voltage is reference to the power
ground.
C2
PULSE
/PULSE
SIGN
/SIGN
43
41
36
37
The drive can accept two different types of
pulse inputs: Line-driver input (max. input
frequency is 500Kpps) and Open-collector input
(max. input frequency is 200Kpps).
Three different pulse commands can be
selected via parameter P1-00. They are A phase
+ B phase (Quadrature), CW pulse + CCW pulse,
and Pulse + Direction.
C3/C4
Position
Pulse
Input
PULL HI_P
PULL HI_S
39
35
When an Open-collector type of pulse is used,
this terminal must be connected to a pull-up
power supply.
C3/C4
High-
speed
Position
Pulse
Input
HSIGN
/HSIGN
HPULSE
/HPULSE
46
40
38
29
The drive can accept two different types of
high-speed pulse inputs: +5V input and Line-
driver input. The max. input frequency is
4MHz.
Three different pulse commands can be
selected via parameter P1-00. They are A phase
+ B phase (Quadrature), CW pulse + CCW pulse,
and Pulse + Direction.
C4-2
