Chapter 4 Parameter Settings|DD Series
4-51
05 Door Close Parameters This parameter can be set during operation.
Door Close initial Speed
Control mode
VF
VFPG SVC FOCPG FOCPM
Factory setting: 2.00
Settings 0.00~120.0Hz
Door Close Distance by Initial Speed
Control mode VF VFPG SVC FOCPG FOCPM
Factory setting: 0
Settings 0~65535 (Unit: pulses number)
Door Close Time by Initial Speed
Control mode VF VFPG SVC FOCPG FOCPM
Factory setting: 0
Settings 0.0~20.0s
Door Close High Speed 1
Control mode VF VFPG SVC FOCPG FOCPM
Factory setting: 15.00
Settings 0.00~120.0Hz
Door Close by Final Speed Begins
Control mode VF VFPG SVC FOCPG FOCPM
Factory setting: 10.0
Settings
0.0~100.0% (0.0％=door completely close, 100.0%= door completely open)
Door Close Final Speed
Control mode VF VFPG SVC FOCPG FOCPM
Factory setting: 5.00
Settings 0.00~120.0Hz
Door Close by Holding Speed begins
Control mode VF VFPG SVC FOCPG FOCPM
Factory setting: 5.0
Settings
0.0~100.0% (0.0％=door completely close, 100.0%= door completely open)
Door Close Holding Speed
Control mode VF VFPG SVC FOCPG FOCPM
Factory setting: 2.00
Settings 0.00~120.0Hz
Door Close Acceleration Time 1
Control mode VF VFPG SVC FOCPG FOCPM
Factory setting: 1.0
Settings 0.1~3600sec
Door Close Deceleration Time 1
Control mode VF VFPG SVC FOCPG FOCPM
Factory setting: 1.0
Settings 0.1~3600sec
Door Close Holding Torque Level
Control mode VF VFPG SVC FOCPG FOCPM
Factory setting: 50.0
Settings 0.0~150.0% (Drive’s rated current)
Please refer to the diagram below and adjust door open/close curve to your requirement.
