GENERAL SM1500
Page 4 - 1 DELTA ELEKTRONIKA B.V. rev. August 2018
4 INSTALLATION
1) HU MID ITY & CON DEN SA TION
• Dur ing nor mal op er a tion, hu mid ity will not harm the power sup -
ply, pro vided the air is not ag gres sive. The heat nor mally pro -
duced in the power sup ply will keep it dry.
• Avoid con den sa tion in side the power sup ply, to pre vent
break-down. Con den sa tion can oc cur dur ing a pe riod the power
sup ply has been switched off (or op er at ing at no load) and the
am bi ent tem per a ture is in creas ing. Al ways al low the power sup -
ply to dry be fore switch ing it on again.
2) TEM PER A TURE & COOL ING
• The stor age tem per a ture range is –40 to +85 °C.
• The op er at ing tem per a ture range at full load is –20 to +50 °C.
This tem per a ture range only holds when the air-in takes and
air-out lets are un ob structed and the tem per a ture of the air-in take
is not higher than +50 °C.
• When the power sup ply is mounted in a cab i net, please note that
the tem per a ture of the air-in take should be kept low and avoid a
short cir cuit in the air flow i.e. the hot air leav ing the air-out lets
en ter ing the air-in takes again.
• Please note: a lower tem per a ture ex tends the life time of the
power sup ply.
3) 19" RACK MOUNT ING
• On both sides in the rack, mount a proper sup port slide that can
hold the weight of the unit. It is ad vised to use a sep a rate slide for
each unit.
• Af ter plac ing the unit(s) on the slide, add all 4 screws to mount the
front pan els of the power sup plies to the ver ti cal rack posts. Use
proper screws in tended for keep ing equip ment of this weight in
po si tion.
• As sum ing the rack is de lib er ately de signed for the weight, stack -
ing of the units is al lowed with out lim i ta tions. See pre vi ous para -
graph for cool ing in struc tions.
4) OP ER ATING THE UNIT FOR THE FIRST TIME
• Check there is no con den sa tion on the unit. If there is, al low some
time to dry.
• Check there is a link be tween + and S+ and be tween – and S– on
the SENSE BLOCK (on rear panel).
• Check there is a link be tween the in puts of the In ter lock (CON A,
rear panel).
• Set the CV and CC po ten ti om eters to min i mum (fully anti clock -
wise). For units with Op tion P220, this is not needed. These units
are set to start at 0 V - 0 A when op er ated for the first time.
• For rec om mended ca ble di am e ters and torque (see ta ble 4 -1).
• With high out put cur rent make sure to use low re sis tive con -
nec tions be tween the power sup ply and the load:
- Mount the ca ble lugs di rectly
on the tinned out put strips
fol lowed by a washer, a split washer and a nut (see fig. 4 - 1).
Al ways in this or der!
- Never place wash ers be tween the lugs and the strips
be cause this can re sult in ex ces sive heat!
- Only use nuts and wash ers sup plied with the unit.
• Switch on unit.
• Dis able the Key lock func tion, see next para graph 5).
• Check the unit is not in Re mote CV or Re mote CC (LED’s for this
func tion should be off). Press the RE MOTE/LO CAL but ton un til
both LED’s are off.
• Turn on the out put by press ing the OUT PUT ON/OFF but ton.
• Turn both the CV and CC po ten ti om e ter a few turns clockwise.
A volt age should now be pres ent on the out put.
• By press ing the DIS PLAY CV/CC SETTING but ton, the me ters
will show the set ting of the CV and CC po ten ti om e ter.
fig. 4 - 1
Low re sis tive ca ble con nec tion by mount ing the
ca bles di rectly on the tinned out put strips
fig. 4 - 2
Pro gram ming by volt age:
left volt age -, right cur rent pro gram ming
fig. 4 - 3
Pro gram ming by cur rent
left volt age -, right cur rent pro gram ming
Unit Out put ca bles
[mm2]
Bolts Torque
[Nm]
SM15-100 16 M8 20
SM35-45 6 M8 20
SM52-30 5 M8 20
SM52AR60 10 M8 20
SM70-22 4 M8 20
SM120-13 2.5 M8 20
SM300-5 1 M8 20
SM400AR8 1.5 M8 20
ta ble 4 - 1
Rec om mended ca ble di am e ters and
mount ing torque
Warn ing: care fully read the chap ter "Safety In struc tions"
in this man ual be fore op er at ing the unit!
