SM1500 SAFETY INSTRUCTIONS
rev. August 2018 DELTA ELEKTRONIKA B.V. Page 2 - 1
2 SAFETY INSTRUCTIONS - SM1500-series
1 Caution
The following safety precautions must be observed during all phases of operation, service and repair of this equipment.
Failure to comply with the safety precautions or warnings in this document violates safety standards of design,
manufacture and intended use of this equipment and may impair the built-in protections. Delta Elektronika shall not be
liable for user’s failure to comply with these requirements.
2 Installation Category
The Delta Elektronika power supplies have been evaluated to installation category II (Over voltage category II).
3 Grounding of Mains Terminals (AC Power Terminals)
This product is a safety Class 1 unit. To minimize shock hazard, the unit must be connected to the AC Power Supply
mains through a three conductor power cable, with the ground wire firmly connected to an electrical ground (safety
ground) at the power outlet.
For units designed to be hard-wired to the mains supply , the protective earth terminal must be connected to the safety
electrical ground before another connection is made. Any interruption of the protective ground conductor, or
disconnection of the protective earth terminal will cause a potential shock hazard that might cause personal injury.
4 Grounding of DC Power Terminals
If the DC power terminal of a unit is specified to sink or source to a maximum of 60VDC, and either the negative or
positive DC power terminal is grounded, the following connections can be considered safe:
- DC power terminals and sense connections
- programming/monitor/status-signals, interlock, Master/Slave-connections, ACF/DCF-relay
- all Delta Elektronika interfaces
Caution 1: If a low voltage unit has both DC power terminals floating, or if the DC terminals are in series with an
external high AC or DC voltage, the lower DC power terminal can exceed the safe value in respect to ground as
specified in the above warning!
Caution 2: Although a high voltage unit is set to a safe voltage below 60VDC, for safety it must always be considered as
a high voltage unit! Wrong operation, a programming error or an external defect can result in an unsafe high DC output
voltage.
Caution 3: When programming a high voltage unit directly via a PC or via a network connection, either ground the
negative power output or use a safety isolated interface!
For more information and schematics regards Grounding and Safety, see the special application note "Safe operation of
a power supply" on the Delta Elektronika website.
5 Fuses
Fuses must be changed by authorized Delta Elektronika service personnel only, for continued protection against risk of
fire.
6 AC Input Ratings
Do not use an AC Supply which exceeds the AC input voltage and frequency rating of this unit. The AC input voltage
and frequency rating of the Delta Elektronika power supply series are stated in the accompanying datasheet.
7 Live Circuits
Operating personnel should not remove the unit covers. No internal adjustment or component replacement is allowed by
non Delta Elektronika qualified personnel. Never replace components with the power cable connected. To avoid injuries,
always disconnect power, remove external voltage sources and discharge circuits before touching components.
8 Parts Substitutions & Modifications
Parts substitutions and modifications are allowed by authorized Delta Elektronika service personnel only. For repairs or
modifications the unit must be returned to a Delta Elektronika service facility.
Warning:
When the positive DC power terminal can exceed 60VDC in respect to the negative DC power terminal,
additional
external measures must be taken to ensure safety isolation of the DC power terminals and sense connections.
Warning:
When the negative power output of the unit can exceed 60VDC / 42.4Vpk in respect to ground, additional
external measures must be taken to ensure safety isolation of the following:
- power out puts and sense connections
- pro gram ming/mon i tor/sta tus-sig nals, In ter lock, Mas ter/Slave-con nec tions, ACF/DCF-re lay
- in ter faces with op er a tional isolation
- non-isolated interfaces.
