PARTS LIST
DESCRIPTIONSTOCK NUMBERQTY
ITEM
M/S PAR
SET C6
power unit
SM500-CP-90
SM1500-CP-30
6
1
*
interface m/s gen 2
int mod m/s 2
62
*
m/s strip 5 6 unitsdwg2536
23
v
cover output parallel 1dwg2532
2
4
v
cover output parallel 2dwg2533
45
v
screw M8X30 SG DIN933 10.9/Geomet-500
M8x30SG DIN933126
nut M8 A2M8 A2 DIN93412
7
washer M8 A2
M8 A2 DIN125A128
lock washer A2
M8 A2 DIN127B129
crinkle washer
M8 SZ DIN137B12
10
v
PT 3.5x30 ro he A2 T10 selftap
3.5x30 A2 T106
11
Load cable cable lug M8Not supplied
4
12
patchcable BK 0.5m RJ45
CBL P SFTP 0.5 BK
5
13
v
patchcable BK 1m RJ45
CBL P SFTP 1 BK
114
v




Tol.: 0.2mm
Delta Elektronika B.V.








MASTER SLAVE
assembly 6 units


A3
25-06-2019
S.Janse
DWG
2
13
14

Master
1
7
9
8
12
10
6
4 5
11
3
8 9
7
10
6

