PARTS LIST
DESCRIPTIONSTOCK NUMBERQTY
ITEM
MS PAR
SET C3
power unit
SM500-CP-90
SM1500-CP-30
3
1
*
interface m/s gen 2
int mod m/s 2
32
*
m/s strip 2 3 unitsdwg2531
23
v
cover output parallel 1dwg2532
2
4
v
cover output parallel 2dwg2533
1
5
v
screw M8X30 SG DIN933 10.9/Geomet-500
M8x30SG DIN933
66
nut M8 A2M8 A2 DIN934
6
7
washer M8 A2
M8 A2 DIN125A
6
8
lock washer A2
M8 A2 DIN127B
69
crinkle washer
M8 SZ DIN137B610
v
PT 3.5x30 ro he A2 T10 selftap
3.5x30 A2 T103
11
Load cable cable lug M8Not supplied
212
patchcable 0.5m RJ45
CBL SFTP 0.5 BK313
v




Tol.: 0.2mm
Delta Elektronika B.V.








MASTER SLAVE
assembly 3 units


A3
25-06-2019
S.Janse
DWG
2
13

4
Master
1
11
7
9
8
12
6
3
6
10
10
5
7
9
8

