PARTS LIST
DESCRIPTIONSTOCK NUMBERQTY
ITEM
M/S PAR
SET C8
power unit
SM500-CP-90
SM1500-CP-30
8
1
*
interface m/s gen 2
int mod m/s 2
82
*
m/s strip 1 2 unitsdwg2530
23
v
cover output parallel 1dwg2532
2
4
v
cover output parallel 2dwg2533
6
5
v
m/s strip 3 4 unitsdwg2534
4
6
v
screw M8X30 SG DIN933 10.9/Geomet-500
M8x30SG DIN933
16
7
nut M8 A2M8 A2 DIN934
16
8
washer M8 A2
M8 A2 DIN125A
169
lock washer A2
M8 A2 DIN127B
1610
crinkle washer
M8 SZ DIN137B
16
11
v
PT 3.5x30 ro he A2 T10 selftap
3.5x30 A2 T10812
Load cable cable lug M8Not supplied
4
13
patchcable BK 0.5m RJ45
CBL P SFTP 0.5 BK
714
v
patchcable BK 1m RJ45
CBL P SFTP 1 BK
115
v




Tol.: 0.2mm
Delta Elektronika B.V.








MASTER SLAVE
assembly 8 units


A3
25-06-2019
S.Janse
DWG
2
14
15

4 5
12
7 11
8
10
9
13
Master
6 3
7
11
1
9
10
8

