Delta 36-T30 - Carton Contents

CARTON CONTENTS
1. Front Guide Rail (1)
2. Rear Guide Rail (1)
3. Guide Tube (1)
4. Fence (1)
5. Support Legs (36-T50
T3
Only) (2)
6. Extension Table (36-T50
T3
Only) (1)
a. 5/16” External Tooth Lockwasher (14)
b. 5/16” Hex Flange Nut (17)
c. 5/16” Countersunk Screw (8)
d. 1/4” Pan Head Screw with Washer (4)
e. 5/16” Hex Socket Screw (17)
f. 1/4-20 x 1/2” Hex Cap Screw (2)
g. Rail Alignment Gauge (1)
1
2
3
4
5
6
l
m
n
d
a b
i j k
e
g
h
f
c
o
p
q
HARDWARE PACKAGE
CARTON CONTENTS
HARDWARE PACKAGE
(included with the 36-T50
T3
)
(included with the 36-T30
T3
)
NOTE: The DELTA
®
36-T30
T3
and 36-T50
T3
are designed to be used with a variety of DELTA
®
table saws. It is also possible to install
this fence on non-DELTA
®
saws. This kit contains a variety of hardware types and sizes, not all of which are necessary to attach
this fence to your specific saw. Use the hardware that best fits your saw and enables you to attach the fence rails and guide tube
securely to the saw.
a. 5/16” External Tooth Lock Washer (10)
b. 5/16” Hex Flange Nut (13)
c. 5/16” Countersunk Screw (6)
d. 1/4” Pan Head Screw with Washer (6)
e. 5/16” Hex Socket Screw (13)
f. 1/4-20 x 1/2” Hex Cap Screw (2)
g. Rail Alignment Gauge (1)
h. 7/32 x 1/2” Flat Washers (4)
i. 1/4-20” Hex Nut (12)
j. 3/8-16” Hex Nut (2)
k. #10-32” Hex Nut (4)
l. 5/16” x 5/8” Flat Washer (12)
m. 10-32 x 1 3/4” Pan Head Bolts (4)
n. #8 x 3/4” Wood Screws (8)
o. 1/4-20 x 1-1/2” Hex Head Screw (6)
p. 1/4-20 x 1 1/2” Countersunk Screw (6)
q. Leveling Feet (2)
5
