AS Series Module Manual
9- 20
Steps for a quick setup
1. Set up the PLC:
Delta Special Driver & AS Remote Modem mode, number of the device: 1; baud rate:
1000kbps; download the parameters.
2. Set up AS00SCM-A; set the ID1 knob to 0 and FORMAT1 to 8; ID2 knob to 9 and FORMAT2 to 7.
3. Supply power to AS00SCM-A and connect AS00SCM-A to the PLC with a CANopen cable.
4. Resupply power to the PLC and the indicator of CARD2 should keep blinking. That indicates
AS00SCM-A and the PLC are connected. The PLC error indicator should be blinking too, since the
setting is not done yet.
5. Use HWCONFIG to scan the connected devices to see if AS00SCM-A is connected.
6. Download the parameters and check if the PLC error indicator has stopped blinking. Then the setting
of one RTU device is complete.
