Chapter 10
CANopen
Function and Operation
10
-
33
10
C.
Cli
ck the Onlin
e
button on the T
oolbar t
o enter on
-
line m
ode.
D.
Click the Scan Net
work
button on the T
oolbar
to scan the net
work.
E.
On the
Ne
tw
ork
menu, click
Master p
arameter
to dis
play the Mast
er Configur
ation dial
og box.
