Delta AS16AP11T-A

AS Series Operation Manual
2-53
_2
Model
Item
AS04PU-A
Electrical isolation
Optocoupler
Input display
When the optocoupler is driven, the input LED indicator is ON.
Weight
120 g
Electrical specifications for the outputs
Model
Item
AS02PU-A AS04PU-A
Number of outputs
Four
Eight
Connector type
Removable terminal blocks
Output form
differential output Transistor-T (sinking) (NPN)
Output current
5 VDC, 20 mA
5-30 VDC, 0.1A
Maximum
load
Resistance
20 mA
0.1A
Inductance
N/A
Bulb
N/A
Maximum
output
frequency
*1
Resistance
200 kHz 100 kHz
Inductance
N/A
Bulb
N/A
Maximum
Response
time
OFF→ON
2.5 μs 5 μs
Weight
120 g
Note *1: Acutal output 4 VDC (high input impedance) to 3.3 VDC (10 mA)/point
