2.9.3 Load Cell Module Dimensions
 AS02LC-A
EXC
-
EX C+
SLD
0V
24V
SE N+
EX C+
SIG+
SE N+
SLD
SIG+
CH2
SEN
-
EXC
-
SIG
-
CH1
SEN
-
SIG
-
02LC
Unit: mm
2.9.4 Load Cell Module Device Setting
(1) AS02LC-A
Refer to the AS Series Module Manual for further information on device settings.
