Delta AS300N-A

AS Series Operation Manual
2-63
_2
Electrical specifications
Item Specifications
Power supply to
device in IO-Link
mode or SIO (DI)
mode
Rated voltage
24 VDC (20.4 VDC~ 28.8 VDC) (9-15%~+20%)
Maximum load
current
0.2A/port
Short-circuit
protection
Yes
Digital inputs in
SIO (DI) mode
Internal I/O
common
NPN, PNP
Input voltage /
current
24 VDC, 5 mA
ON voltage
>15 VDC
OFF voltage
<5 VDC
Input filter time
No filter, 1 ms (default), 2 ms, 4 ms, 8 ms, 16 ms, 32 ms, 64 ms
,
128 ms, 256 ms
Digital outputs in
SIO (DO) mode
Internal I/O
common
NPN, PNP
Output
voltage /
current
24 VDC (20.4 VDC~ 28.8 VDC), 0.1A/port
Short-circuit
protection
Yes
Leakage current
<0.1 mA
Residual
voltage
<1.5 VDC
Digital inputs for
pin 2 in IO-Link
mode
Internal I/O
common
NPN, PNP
Input voltage /
current
24 VDC, 2 mA
ON voltage
>15 VDC
OFF voltage
<5 VDC
Input filter time
No filter, 1 ms (default), 2 ms, 4 ms, 8 ms, 16 ms, 32 ms, 64 ms
,
128 ms, 256 ms
Power consumption
0.8 W
Weight
133g
