Delta DE212 GLOBAL - Page 7

User and Installation Manual, DE212 GLOBAL
DELTA RC AS Page 7 of 36
Document 02743
Receiver connections, connector P3:
Functions installed with receiver software program: 02046
Conn.
P3
Functional description
1
External override
The Deadman function is active as long as this input is
low, connected to GND
SW2-3 : External override
ON= Ext. override active. OFF=Ext.
override disabled
2
Not in use, for future expansion.
Do not connect
3
External STOP.
Stops all functions in the receiver when connected to GND
This function is always enabled
4
Not in use, for future expansion.
Do not connect
5
GND, ground or common terminal.
Same as P1, term. 7
NOTES:
• Input voltage is 11 to 35 V DC. All outputs give input voltage when activated.
• NOTE: Input voltage above 35V, will shut down the receiver.
• Note that the potential between the minus pole and ground, must not be greater than 50VDC/AC peak.
• The timer warning output operates as follows: when the Deadman function is activated, the time warning
output also go active, supplying 12/24V out. When 30 seconds are left of the 2 min. time period, the
standard period, the output change from a steady output, to an off/on signal during the last 30 seconds of
the time period. The output is intended for connection to an indicating lamp, visible for the operator. The
on/off flashing lamp is intended to warn the operator to restart the time period.
• The timer beeper output is active only as long as the warning signal is flashing.
If external connection box is delivered, the connections are as follow:
Cable
marking
Receiver
connector
Function
YE-GN
Not in use
6
6
Interlock
5
5
STOP
4
4
Deadman output
3
3
Extra function
2
2
Timer warning
1
1
Timer beeper
7
7
Minus-pole, input voltage
8
8
Plus-pole, input voltage, 12/24VDC
