• "TO RADIO" connectors:
"SP" – connect to the radio audio output (speaker or headphone output)
"MIC" – we connect in the microphone input of the radio
"GND" – we connect with the mass of the radio
"PTT" – output for PTT control (open collector)
• Potentiometer
"RX" – adjusting the audio level of the radio
"TX" - adjusting the audio level of the suond card
Recommendations, safety of users:
• Remark! Since the audio signal from the computer should have a minimum level of 0.8Vpp, it is
recommended to set the volume of the speaker on the computer to 100%
• we recommend using cheap external USB sound cards. In older computers, laptopswith built-in internal sound
cards can cause unstable system performance
• read the radio manual carefully before connecting to the interface. In some cases, the PTT connection may
require a resistor
• the interface requires appropriate cables to connect to the radio and sound card. These cables must be made by
yourself
• How to connect the Baofeng UV-5R radio to the DIGIVOX-2 interface can be found on the last page of the
instruction
Technical specifications:
Work mode passive
Connector type „PC AUDIO” 2 x Jack 3,5mm, female, stereo
Connector type „TO RADIO” 4 X cable terminal
PTT output type OC, max. 30V / 300mA
PTT switch time 20ms
PTT Off time 5ms
Minimal value od audio signal 600mV RMS
Galvanic separation 600V
Operational temerature -20 °C ... 55 °C
Dimensions 118 x 30 x 59 mm
Weight 95g
Warranty 24 months
Waste electrical and electronic equipment must not be disposed of together with ordinary
household waste. According to the EU WEEE Directive, separate disposal methods must be used for
waste electrical and electronic equipment.
Manufacturer:
DELTA-OPTI Monika Matysiak, 60-713 Poznań, ul. Graniczna 10, Polska
www.delta.poznan.pl
RoHs
