English-19
MODEL B05S100 B05S101 B07S415 B07E415 B07PS415
Cooling
Method
Natural air circulation
Safety Approval
CE／UL
(Note 4)
／KCC
(Note 4)
Waterproof
Degree
IP65／NEMA4
Operation
Voltage
(Note 5)
DC +24V（-10% ~ +15%）(please
use isolated power supply)
DC +24V（-10% ~
+15%）(please use
isolated power
supply)
DC +24V（-10% ~
+15%）
（has built-in
isolated power
circuit
(Note 3)
）
DC +24V（-10% ~
+15%）(
please use
isolated power
supply)
Voltage
Endurance
AC500V for 1 minute (between charging (DC24V terminal) and FG terminals)
Power
Consumption
(Note 5)
3.0W 5W 7.5W 5W
Backup Battery 3V lithium battery CR2032 x 1
Backup Battery
Life
It depends on the temperature used and the conditions of usage,
about 3 years or more at 25
o
C.
Operation
Temp.
0
o
C ~ 50
o
C
Storage Temp.
-20
o
C ~ +60
o
C
Ambient
Humidity
10% ~ 90% RH [0 ~ 40
o
C], 10% ~ 55% RH [41 ~ 50
o
C]
Pollution Degree 2
Vibration
IEC 61131-2 compliant 5Hz
≦
f
＜
8.3Hz = Continuous: 3.5mm, 8.3Hz
≦
f
≦
150Hz =
Continuous: 1.0g
Shock IEC 60068-2-27 compliant 15g peak for 11 ms duration, X, Y, Z directions for 6 times
Dimensions
(W) x (H) x (D)
mm
184 x 144 x 50 215 x 161 x 50
Panel Cutout
(W) x (H) mm
172.4 x 132.4 196.9 x 142.9
Weight Approx.670g Approx.970g
NOTE
1) The half-life of backlight is defined as original luminance being reduced by 50% when the maximum
driving current is supplied to HMI. The life of LED backlight shown here is an estimated value under
25
o
C normal temperature and humidity conditions.
2) USB Host port can provide up to 5V/ 500mA of power.
3) The withstand voltage of the isolated power circuit is 1500V peak for 1 minute.
4) Some models are in the process of application to UL and KCC certification. For more information,
please consult our distributors.
5) The value of the power consumption indicates the electrical power consumed by HMI only without
connecting to any peripheral devices. In order to ensure the normal operation, it is recommended to
use a power supply which the capacity is 1.5 ~2 times the value of the power consumption.
6) Users can download the DOPSoft software, the program editor of Delta HMI product and the user
manual via the following link: http://www.delta.com.tw/ia/.
7) The content of this quick start may be revised without prior notice. Please consult our distributors or
download the most updated version at http://www.delta.com.tw/ia/.
