MODEL B07S515 B07E515 B07PS515 B08S515 B08E515 B10S615 B10E615
Safety Approval
CE／UL
(Note 4)
／KCC
(Note 4)
Waterproof
Degree
IP65／NEMA4
Operation
Voltage
(Note 5)
DC +24V
(-10% ~
+15%)
(please
use
isolated
power
supply)
DC +24V
(-10% ~
+15%)
(has built-in
isolated
power
circuit
(Note 3)
)
DC +24V
(-10% ~
+15%)
(please
use
isolated
power
supply)
DC +24V
(-10% ~
+15%)
(please use
isolated
power
supply)
DC +24V
(-10% ~
+15%)
(has built-in
isolated
power circuit
(Note 3)
)
DC +24V (-10% ~ +15%)
(has built-in isolated power
circuit
(Note 3)
)
Voltage
Endurance
AC500V for 1 minute (between charging (DC24V terminal) and FG terminals)
Power
Consumption
(Note 5)
7.68W 5.2W 7.8W 12W
Backup Battery 3V lithium battery CR2032 x 1
Backup Battery
Life
It depends on the temperature used and the conditions of usage, about 3 years or more at
25
o
C.
Operation
Temp.
0
o
C ~ 50
o
C
Storage Temp.
-20
o
C ~ +60
o
C
Ambient
Humidity
10% ~ 90% RH [0 ~ 40
o
C], 10% ~ 55% RH [41 ~ 50
o
C]
Pollution Degree 2
Vibration
IEC 61131-2 compliant 5Hz
≦
f
＜
8.3Hz = Continuous: 3.5mm, 8.3Hz
≦
f
≦
150Hz =
Continuous: 1.0g
Shock IEC 60068-2-27 compliant 15g peak for 11 ms duration, X, Y, Z directions for 6 times
Dimensions
(W) x (H) x (D)
mm
184 x 144 x 50 227.1 x 174.1 x 61 272 x 200 x 61
Panel Cutout
(W) x (H) mm
172.4 x 132.4 219.4 X 166.5 261.3 X 189.3
Weight Approx.800g Approx.1226g Approx.1520g
NOTE
1) The half-life of backlight is defined as original luminance being reduced by 50% when the maximum
driving current is supplied to HMI. The life of LED backlight shown here is an estimated value under
25
o
C normal temperature and humidity conditions.
2) USB Host port can provide up to 5V/ 500mA of power.
3) The withstand voltage of the isolated power circuit is 1500V peak for 1 minute.
4) Some models are in the process of application to UL and KCC certification. For more information,
please consult our distributors.
5) The value of the power consumption indicates the electrical power consumed by HMI only without
connecting to any peripheral devices. In order to ensure the normal operation, it is recommended to
use a power supply which the capacity is 1.5 ~2 times the value of the power consumption.
6) Users can download the DOPSoft software, the program editor of Delta HMI product and the user
manual via the following link: http://www.delta.com.tw/ia/.
