繁中-18
DOP-B08S(E)515
T=1.6mm(0.06") ~
5.0mm(0.19")
(2.06")
174.1(6.85")
227.1(8.94")
0
+0.04"
(8.63" )
0
219.4
+1
+0.04"
6.55"
0
+1
166.5
0
NOTE:
4-R1.0(0.04")
52.3
T
DOP-B10S(E)615
272(10.71")
200(7.88")
188.3(7.41")
51.9(2.04")
T
Note:
T=1.6mm(0.063")~6mm(0.24")
261.3
+1.0
0
(10.29"
+0.04"
0
)
189.3
+1.0
0
(7.45"
+0.04"
0
)
單位：mm (inches)
單位：mm (inches)
