- 3 -
DVP06XA-E2
Max. rated power
consumption
2.5W, supplied by external power source
Connector European standard removable terminal block (Pin pitch: 5mm)
Operation/storage
Operation: 0°C~55°C (temp.), 5~95% (humidity), Pollution degree2
Storage: -25°C~70°C (temp.), 5~95% (humidity)
Vibration/shock
immunity
International standards: IEC61131-2, IEC 68-2-6 (TEST Fc)/
IEC61131-2 & IEC 68-2-27 (TEST Ea)
Series connection to
DVP-PLC MPU
The modules are numbered from 0 to 7 automatically by their
distance from MPU. Max. 8 modules are allowed to connect to MPU
and will not occupy any digital I/O points.
Functions Specifications
Common specifications
Digital data format 2’s complement of 16 bits
Response time 400μs / each channel
Overall accuracy
0.5% when in full scale within the range of (25°C, 77°F);
1% when in full scale within the range of (0 ~ 55°C, 32 ~
131°F)
Isolation
Optical coupler isolation between digital circuits and analog
circuits. No isolation among analog channels.
500VDC between digital circuits and Ground. 500VDC
between analog circuits and Ground. 500VDC between
analog circuits and digital circuits. 500VDC between 24VDC
and Ground
Analog / Digital
Voltage input Current input
Analog input channel 4 channels / each module
Range of analog input ±10V ±5V
±20m
0 ~ 20mA 4 ~ 20mA
Range of digital conversion ±32,000 ±32,000
±32,0
00
0 ~ 32,000 0 ~ 32,000
Max./Min. output range of
digital data
±32,384 ±32,384
±32,3
84
-384 ~+32,384 -384 ~+32,384
Hardware Resolution 14 bits 14 bits
14
bits
13 bits 13 bits
Input impedance ≧1MΩ 250Ω
Range of absolute input ±15V ±32mA
Average Function
Supported. Available for setting up sampling range in CR#8 ~
CR#11. Range: K1 ~ K100.
Self-diagnosis Upper and lower bound detection in all channels
Digital / Analog
Voltage output Current output
Analog output channel 2 channels / each module
Range of analog output -10V ~ 10V 0 ~ 20mA 4mA ~ 20mA
Range of digital conversion -32,000 ~ +32,000 0 ~ +32,000 0 ~ +32,000
Max./Min. input range of digital
data
-32,768 ~ +32,767 0 ~ +32,767 -6,400 ~ +32,767
Hardware Resolution 14 bits 14 bits 14 bits
Max. output current 10mA －
Tolerance load impedance
≧1KΩ
≦500Ω
Output impedance ≦0.5Ω ≧1MΩ
To Next Page
