- 4 -
Protection
Voltage output is protected by short circuit. Short circuit
lasting for too long may cause damage on internal circuits.
Current output can be open circuit.
Control Register
CR# Attrib. Register name Explanation
#0 O R Model name
Set up by the system:
DVP06XA-E2 model code = H’00C4
#1 O R Firmware version Display the current firmware version in hex.
#2 O R/W CH1 Input mode setting
Input mode: Default = H’0000. Take CH1 for
example:
Mode 0 (H’0000):Voltage input (±10V)
Mode 1 (H’0001):Voltage input (±5V)
Mode 2 (H’0002):Voltage input (0 ~+10V)
Mode 3 (H’0003):Voltage input (0 ~+5V)
Mode 4 (H’0004):Current input (±20mA)
Mode 5 (H’0005):Current input (0 ~+20mA)
Mode 6 (H’0006):Current input (4 ~+20mA)
Mode -1 (H’FFFF):Channel 1 unavailable
#3 O R/W CH2 Input mode setting
#4 O R/W CH3 Input mode setting
#5 O R/W CH4 Input mode setting
#6 O R/W CH5 output mode setting
Output mode: Default = H’0000. Take CH5
for example:
Mode 0 (H’0000):Voltage output (±10V)
Mode 1 (H’0001):Current output (0~+20mA)
Mode 2 (H’0002):Current output (4~+20mA)
Mode -1 (H’FFFF):Channel 5 unavailable
#7 O R/W CH6 output mode setting
#8 O R/W CH1 sampling range
Set sampling range in CH1 ~ CH4:
Range = K1 ~ K100
Default = K10
#9 O R/W CH2 sampling range
#10 O R/W CH3 sampling range
#11 O R/W CH4 sampling range
#12 X R CH1 average input value
Average value of input signals at CH1 ~
CH4
#13 X R CH2 average input value
#14 X R CH3 average input value
#15 X R CH4 average input value
#16 X
R/W
CH5 output signal value
Voltage output range: K-32,000~K32,000.
Current output range: K0~K32,000.
Default: K0.
#17 X
R/W
CH6 output signal value
#20 X R CH1 present input value
Present value of input signals at CH1 ~ CH4
#21 X R CH2 present input value
#22 X R CH3 present input value
#23 X R CH4 present input value
#28 O R/W Adjusted Offset value of CH1
Set the adjusted Offset value of CH1 ~ CH6
Default = K0.
Definition of Offset in DVP06XA -E2:
The corresponding voltage (current) input
value when the digital output value = 0
#29 O R/W Adjusted Offset value of CH2
#30 O R/W Adjusted Offset value of CH3
#31 O R/W Adjusted Offset value of CH4
#32 O R/W Adjusted Offset value of CH5
#33 O R/W Adjusted Offset value of CH6
#34 O R/W Adjusted Gain value of CH1
Set the adjusted Gain value in CH1 ~ CH6
Default = K16,000. Definition of Gain in
DVP06XA-E2: The corresponding voltage
(current) input value when the digital output
value = 16,000.
#35 O R/W Adjusted Gain value of CH2
#36 O R/W Adjusted Gain value of CH3
#37 O R/W Adjusted Gain value of CH4
#38 O R/W Adjusted Gain value of CH5
#39 O R/W Adjusted Gain value of CH6
Adjusted Offset Value, Adjusted Gain Value:
To Next Page
