- 5 -
CR# Attrib. Register name Explanation
Note 1: When using Mode 6 for input or Mode 2 for output, the channel do NOT provide
setups for adjusted Offset or Gain value.
Note 2: When input mode changes, the adjusted Offset or Gain value returns to defaults.
#40 O R/W Set value changing prohibited
Prohibit set value changing in CH1 ~ CH4
Default= H’0000.
#41 X R/W Save all the set values Save all the set values, Default =H’0000
#43 X R Error status
Register for storing all error status. Refer to
table of error status for more information.
#100 O R/W Enable/Disable limit detection
Upper and lower bound detection, b0~b5
corresponds to CH1~CH6 (0: Disable/ 1:
Enable). Default= H’0000.
#101 X R/W Upper and lower bound status
Display the upper and lower bound status.
(0: Not exceed /1: Exceeds upper or lower
bound value), b0~b5 corresponds to
Ch1~Ch6 for lower bound detection result;
b8~b13 corresponds to CH1~CH6 for upper
bound detection result..
#102 O R/W Set value of CH1 upper bound
Set value of CH1~CH6 upper bound.
Default = K32000.
#103 O R/W Set value of CH2 upper bound
#104 O R/W Set value of CH3 upper bound
#105 O R/W Set value of CH4 upper bound
#106 O R/W Set value of CH5 upper bound
#107 O R/W Set value of CH6 upper bound
#108 O R/W Set value of CH1 lower bound
Set value of CH1~CH6 lower bound.
Default = K-32000.
#109 O R/W Set value of CH2 lower bound
#110 O R/W Set value of CH3 lower bound
#111 O R/W Set value of CH4 lower bound
#112 O R/W Set value of CH5 lower bound
#113 O R/W Set value of CH6 lower bound
#114 O R/W Output update time of CH5
Set output update time of CH5 ~ CH6
#115 O R/W Output update time of CH6
#118 O R/W
LV output mode setting of Ch5
~ Ch6
Set the output mode of CH5~CH6 when the
power is at LV (low voltage) condition.
Default=0
Symbols: O: When CR#41 is set to H’5678, the set value of CR will be saved.
X: set value will not be saved.
R: able to read data by using FROM instruction.
W: able to write data by using TO instruction.
※ CR#43 List of Error Status Codes:
Description
bit0 K1 (H’1) Abnormal power supply bit6 K64 (H’40) CH4 abnormal value of conversion
bit1 K2 (H’2) Reserved bit9 K512(H’0200) Mode setting error
bit2 K4 (H’4)
Value of conversion exceeds the
upper and lower values
bit10 K1024(H’0400) Average setting error
bit3 K8 (H’8) CH1 abnormal value of conversion bit11 K2048(H’0800) Upper & lower bound setting error
bit4 K16 (H’10) CH2 abnormal value of conversion bit12 K4096(H’1000) Prohibit setting value modification
bit5 K32 (H’20) CH3 abnormal value of conversion bit13 K8192(H’2000) Lower level module disconnected
Note: Each error status corresponds to a bit (b0~b13). Sometimes two or more error status
occur at the same time, 0 stands for normal / no error, while 1 means error status.
※ Module Reset (Available for firmware V1.14 or above): When modules need reset, write
H’4352 in CR#0 then disconnect and turn on the power again. The resetting initializes
parameter setups to provide normal functions for other modules. Connect to only one module
during reset, wait 1 second before disconnecting the power.
