DVP-ES3 Series Operation Manual
5-30
_5
Description
bit5 K32 (H’20) CH3 Conversion error bit13 K8192 (H’2000)
Communication breakdown on
next module
 Note: Each error status is determined by the corresponding bit (b0 ~ b13) and there may be more than 2 errors
occurring at the same time. 0 = normal; 1 = error
Adjust A/D Conversion Curve
You can adjust the conversion curves according to the actual needs by changing the Offset value (CR#28 ~ CR#31) and
Gain value (CR#34 ~ CR#37).
Offset: The corresponding voltage/current input value when the digital output value = 0.
Gain: The corresponding voltage/current input value when the digital output value = 16,000.

Equation for voltage input Mode0 / Mode2:
( )
OffsetGainOffset
V
VX
Y −








−××= 32000
10
16000
)(
)(
Y=Digital output, X=Voltage input
Resolution: 0.3125mV = 20V/64,000 = 10V/32,000

Equation for voltage input Mode1 / Mode3:
( )
OffsetGainOffset
V
VX
Y −








−××= 32000
5
16000
)(
)(
Y=Digital output, X=Voltage input
Resolution: 0.15625mV = 10V/64,000 = 5V/32,000

Equation for current input Mode4 / Mode5:
( )
OffsetGainOffset
mA
mAX
Y −








−××= 32000
20
16000
)(
)(
Y=Digital output, X=Current input
Resolution:
0.625μA = 40mA/64,000 = 20mA/32,000

Equation for current input Mode6:
( )
640019200640032000
20
16000 −








−××=
)(
)(
mA
mAX
Y
Y=Digital output, X=Current input
Resolution: 0.5μA = 16mA/32,000
