DVP-ES3 Series Operation Manual
6-14
Additional remark
You create a contact and a coil by typing simple instructions. Refer to the description below. The instructions
typed are not case-sensitive.
To Insert a normally-open contact (contact A), type “A <device address>”
To insert a normally-closed contact (contact B), type “B <device address>”
To insert an output coil (OUT), type “O <device address>”
6.5.4
Basic Editing ─ Selecting a Network and Operation
Before you select an object in a network, press Esc on the keyboard, or click on the toolbar. After the
cursor appears as a small arrow, click the object in the network. The basic selection shows below.
