7 - English
1. Grinder
2. Wrench
3. Eye shield (2)
4. Eye shield knob (2)
5. Eye shield bushing (2)
6. Left side spark guard
7. Right side spark guard
8. Left side tool rest
9. Right side tool rest with V-groove
10. Eye shield bolt (2)
11. 5/16-18 x 5/8" Hex head screw (2)
12. 5/16-18 x 1/2" Hex head screw (2)
13. 1/4-20 x 1/4" Hex head screw (2)
14. 3/4" Flat washer (4)
15. 1/4" Flat washer (4)
CARTON CONTENTS
UNPACKING AND CLEANING
Carefully unpack the machine and all loose items from the shipping container(s). Remove the rust-preventative oil from
unpainted surfaces using a soft cloth moistened with mineral spirits, paint thinner or denatured alcohol.
Do not use highly volatile solvents such as gasoline, naphtha, acetone or lacquer thinner for cleaning your
machine.
After cleaning, cover the unpainted surfaces with a good quality household floor paste wax.
3
4
5
6
10
11
12
13
14
15
2
7
8
9
Fig. 1
1
